The IKS2700 is a multifunctional self-service Kiosk comes with electronic payment systems and multiple functions. It can be connected to various modular equipment such as NFC proximity card readers, receipt printers and scanners etc. which can be widely used as a self-service machine for restaurant food ordering, cinemas ticket purchasing, airport check-in, retail store counter and other purposes. The system offers customized CPU options that users can choose from 8th Gen Intel® Core™ or AMD Ryzen™ Embedded V1000 processor. The IKS2700 has a 27-inch 1920x1080 resolution screen and 10-point projected capacitive touch panel. It adopts a modular design concept to meet the needs of different fields that not only can the upper half of the fuselage be equipped with a base or wall-mounted design, but also provides various optional functional modules that can be selected according to different requirements and fully meet the needs of smart retail applications.
IKS2700 PRODUCT PAGE
The MPT-500R is a compact intelligent gateway computer designed for railway applications. The system uses the latest Intel low-power processors with high-speed LPDDR4 memory and supports 2.5 Gbps high-speed Ethernet. It provides two PoE ports, providing power to the camera and performing artificial intelligence identification. The MPT-5000R supports a wide temperature operating range of -30°C to +70°C and up to 3Grms/3~500Hz vibration resistance, allowing the system to operate stabely even in harsh environments. It also provides expansion slots for connection to 5G, 4G/LTE or WiFi module to achieve dual wireless broadband backup. It is designed with an innovative shaft mechanism that requires only simple tools to disassemble and maintain the system. The product has obtained the CE/FCC safety certification and passed the EU EN501555 rail and EN45545-2 rail-flame-resistant certifications that helps solve customers' safety needs in the rail transit environment.
MPT-500R PRODUCT PAGE
The CMB100M is an industrial-grade AI computing system aiming at ultra-speed demand of AI analytics or machine learning applications. Users can insert one NVIDIA GeForce RTX 30 series graphics card at the same time for AI identification purpose and all data can be stored within numbers of storage deveices. The rich I/O interfaces includes USB ports, serial ports and dual GbE LAN ports. The system supports 9th Gen Intel® Core™ desktop deca-core processors that can operate at temperatures between 0°C and 45°C and vibration at 3Grms. It features iSMART energy-saving technology for automatic system power on/off scheduling, power resume control and boot-up in low temperature environments. The CMB100M comes with 500W (a maximum of 850W can be replaced) and supports IEC 62368-1 ATX power supply to meet the needs of various power supply requirements. In addition, it supports M.2 for 4G/LTE or WiFi module for network connection purposes.
CMB100 PRODUCT PAGE
The SP-63E is an extreme performance video wall signage player featuring up to 24x HDMI display outputs for 8K/12K video wall or menu board signage display applications in the smart retail market. Powered by 8th Gen Intel® Core™ processor, it offers optimal performance and cost-optimized video wall signage solutions, built with hardware EDID emulation, last frame capture and display status monitoring functions. The SP-63E allows users to remotely check on-site status and to solve any arising display and cable issues. It implements Intel® Arria® 10 FPGA modules, which are powered independently, capture and display the last video frame in case of system malfunction. The system also supports IBASE unique iSMART energy-saving and Observer remote control technologies that enables power on/off scheduling and power resume functions remotely. It can also integrate with Intel OpenVINO toolkit allowing future expansion with analytics and deep learning technologies for advanced AI workload.
The AMI230 is a robust embedded system based on the 9th/8th Gen Intel® Core™ platform. Developed for smart factory, industrial automation, AIoT and other applications in harsh environments, the rugged AMI230 delivers exceptional computing and graphics performance with an extended operating temperature range of -20°C to 70°C, operating vibration up to 3Grms and over/under/reverse voltage protection.The AMI230 houses the Intel® Q370 MB230AF motherboard and is equipped with multiple high speed I/O including 8x USB 3.1, 4x COM, and 3x M.2 (B-Key, E-Key & M-Key) for NVMe storage, WiFi and 4G/LTE options, and HDMI/DP/DVI-D display interface. It also features four Gigabit Ethernet ports making it highly suitable for network related applications, iAMT (11.6) for system remote management and repair, TPM (2.0) security for preventing phishing attacks, and iSMART green technology for power on/off scheduling and power resume functions.
AMI230 PRODUCT PAGE
The MRD-286 is an EN50155 certified AIO 28.6" bar-type panel PC. It integrates an Intel® Pentium® Processor, powered by a 24VDC or 110VDC power input. Built with an ultra-wide TFT active matrix LCD screen, the system can ideally serve as signage display delivering advertising and providing passengers with the current information on arrival and departure times at targeted areas in the vicinity of airports or train stations. The MRD-286 complies with EN50155 international standards, ready to be deployed in various rolling stock applications where rigorous shock and vibration requirements should be met. Its sunlight readable panel provides enhanced graphical performance (1920 x 540) with a wide viewing angle of 178 degrees, ensuring excellent visibility from any direction. The unit has an IP-65 rated front panel and supports up to 8GB of system memory, a 64GB SSD storage, and useful I/O interfaces including an M12 GbE connector, an RS-232/422/485 port and two USB 2.0 ports.
MRD286 PRODUCT PAGE
The MPT-1000R Intelligent Traffic Image Computer was developed for rolling stock applications, with features that meet IIOV, Intelligent Internet of Vehicle and harsh outdoor environment requirements. The shock-resistant system is powered by an Intel® Atom™ x7 processor, operating in extended temperatures between -40°C and 70°C and with 9V-36VDC power input. It has robust M12 waterproof connectors and waterproof antenna connectors that ensure fault-free data transmission in rail vehicle monitoring & railway track side control box applications. Featuring a unique one-click recovery of peripheral expansion card as well as automatic voltage protection, it is certified with EN50155 and EN45545 fire test standards. Designed for ease of use and maintenance, the innovative MPT-1000R overcomes space constraints and high installation costs, supporting an all-in-one cable-free setup with high-speed connectors that handle power and interface requirements without a glitch.
MPT-1000R PRODUCT PAGE
The MPT-8000AR embedded system was designed for the Intelligent IoV (The internet of vehicles) market and is certified with EN50155 rolling stock standards and EN45545 fire safety parameters. It has an innovative modular design that satisfies diverse applications with easy peripheral replacement and expansion. The system can be equipped with video cameras and sensors to scan for traffic signs or signals to control speed or to detect static obstacles in time to stop based on data analysis. Vehicle and passenger information can also be transmitted via cloud to the control center for remote monitoring to ensure a safe journey for passengers. The MPT-8000AR features self-debugging and battery power control. GPIO and G-sensor control software Utility with system hardware monitoring technology allows connection to various devices for enhanced reliability and availability. The solution can be extended to intelligent surveillance equipment and vehicle network management systems.
MPT-8000AR PRODUCT PAGE
The VINO2100 is an artificial intelligence image recognition kiosk developed for the AI image recognition market. It is equipped with a high-performance Intel Core CPU and a reliable industrial motherboard populated with both active and passive components that ensure 24/7 data processing and system operation without breakdown. The system supports infrared cameras and high-resolution digital lenses together and deploys the Intel OpenVINO toolkit to speed up image recognition. It has a thin and light weight design, with smooth and attractive streamlined round edge. Following the worldwide outbreak of COVID-19, it can be used to intercept people not wearing face mask and who fail the body temperature test. The system can be installed in train stations, airports, shopping malls, schools or hospitals to maintain social distancing and conduct massive temperature screening. The built-in medical grade camera offers precise body temperature test so won’t mix up with face or drink temperature.
The SW-101-N is a waterproof digital signage player designed for both indoor and harsh outdoor environments. It is built to withstand dust, water and extreme temperatures in mind, ensuring the system’s stable operation and reliability in harsh industrial environments. It meets IP68 standards, allowing it to handle submersion in water for up to 30 minutes at a depth of 1.5 meters. The black-color waterproof enclosure utilizes a C3 HDMI connector and M12 I/O interface connectors for two USB 2.0, one Gigabit LAN, one RS232, DC power input, and digital I/O. Two antenna N jack type connectors have waterproof design as well. Aside from being fanless, the unit has a wide operating temperature range of -40°C ~ 75°C.
SW-101-N PRODUCT PAGE
The SI-324 is a digital signage player that supports 4 independent displays with individual 4K resolution and provides flexible settings for video wall configurations. It supports the latest Ryzen™ Embedded V1000 processors and integrates IBASE sole iCONTROL intelligent energy-saving green technology and the Observer remote monitoring technology. It also built in with hardware EDID function.
SI-324 PRODUCT PAGE
The MAI602-M4D80 is a fanless embedded system designed for motion control applications in the automation market. It provides excellent computing power and has a built-in 4-axis motor control module that meets the performance and positioning accuracy requirements of high-performance servo amplifiers. The system utilizes side openings for entry and exit when routing cables of expansion modules.
MAI602-M4D80 PRODUCT PAGE
