RISC Platform

IBRK100

Low-Power 2.5” SBC with MediaTek Genio 720 / MT8391 or MediaTek Genio 520/MT8371 Processor

  • MediaTek Genio 720 / MT8391 2.6GHz or MediaTek Genio 520/MT8371 2.2GHz processor
  • On-board LPDDR5(X) 6400MT/s, 4GB or 8GB
  • On-board 64GB or 128GB UFS Flash for O.S.
  • 10 TOPS MediaTek 8th Gen NPU
  • HDMI (4K60) or LVDS (FHD), DP over Type-C (2560x1600)
  • Embedded I/O for COM, CAN-FD, GPIO, USB, Ethernet
  • Supports M.2 E-Key for the wireless expansion
  • Supports Ubuntu and Android
  • NEW
Form Factor 2.5-inch SBC
Processor MediaTek Genio 720
2x A78 2.6GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cache
MediaTek Genio 520
2x A78 2.2GHz L2 256KB, 6x A55 2.0GHz L2 128KB, shared 1MB L3 cache
System Memory On-board LPDDR5(X) 6400MT/s, 4GB or 8GB
Flash Memory On-board 64GB or 128GB UFS flash for O.S.
Display 1x HDMI (4K60) / 1x LVDS (FHD)
1x DP over Type-C (2nd display only, 2560x1600)
*HDMI and LVDS mutually exclusive
Video Codec Decode: 4K60fps, VP9, H.265, H.264
Encode: 4K30fps, H.265, H.264
Graphics ARM Mali-G57 MC2, OpenGL ES 3.2,
Vulkan 1.1, OpenCL 2.2
Edge I/O 1x COM port (RS-232/422/485)
1x RJ45 GbE LAN port
1x HDMI (4K60)
1x On/Off button
1x Reset button
1x USB 3.2 Type-C
2x USB 2.0 Type-A
1x Micro SD Slot
1x Audio Line-Out
1x LED
Internal I/O 1x RS-232 (2-wire, Debug only)
1x CAN-FD
1x LED
1x Download Button
1x 4-Pin Slide Switch Auto Power/LCD Power/ Backlight Power control
1x MIPI-CSI2 (4-Lane)
1x RTC Battery Connector
Expansion IO 1x M.2 E-Key (2230) w/ PCIe Gen 2 x1, USB 2.0
4x GPIO
Watchdog 256 Levels, 0~128 Secs
Dimensions 100mm x 72mm (3.94" x 2.83")
Power Input 12V DC-in by DC-Connector
Operating Temperature -20°C~+80°C (-4°F~176°F)
Relative Humidity 90% (non-condensing @60°C)
OS Support Android 16, Ubuntu 24.04, Other OS (by request)
Certification CE/ FCC Class-B
DATASHEETS IBRK100
