Network Appliance

INA3608

Mainstream 1U Network Security Server with 13th Gen Intel® Core™ Processors (formerly Raptor Lake-S) & up to 10 GbE Ports

  • 13th Gen Intel® Core™ Processors with PCH R680E
  • 2x DDR5 UDIMM 4800MHz (ECC)
  • 4x 2.5GbE RJ45 with 1 pair bypass on board
  • 2x Gbe SFP ports on board
  • Optional NIC slot
  • 1x SATA/NVMe M.2
  • 1x PCI-E x8 expansion slot
  • 600W 1+1 redundant power supply
  • NEW

The INA3608 is a 1U network security server powered by the high-performance 13th Gen Intel® Core™ processors (formerly Raptor Lake-S). The server is an indispensable component of modern network infrastructure, serving a wide range of applications to protect against threats, optimize performance, and maintain compliance with security and privacy regulations.


The INA3608 appliance offers versatility, making it a vital element in ensuring network reliability and security in an ever-evolving digital landscape. It provides a multitude of network connectivity options, including 4x 2.5GbE RJ45 ports with 1 pair bypass, 2x GbE SFP ports, and an optional NIC slot, enabling efficient data traffic management. With expansion capabilities, including 1x PCI-E Gen5 x8 slot for SSL cards and 1x PCI-E Gen5 x8 slot for IBN modules, as well as storage options like 1x 2.5" HDD/SSD, 1x SATA DOM, and 1x 2280 M.2 slot, the server can be adapted to various network configurations.


INA3608 is a 1U network security server powered by the high-performance
INA3608 INTRODUCTION VIDEO

The inclusion of 2x DDR5 UDIMM memory running at 4800MHz ensures swift and reliable data processing. For uninterrupted operation and system reliability, the server come equipped with 600W 1+1 redundant or 500W single power supply. Another model, the INA3606, is available with 12th Gen Intel Core processors. The INA3608 and INA3606 exemplify IBASE's commitment to providing advanced solutions for network security and data processing.

CPU LGA1700 Socket for 13th Gen Intel® Core i Processors
Chipset Intel® PCH R680E
Memory 2x DDR5 UDIMM 4800 MHz, up to 128 GB
Display 1x LCM
Ethernet 4x 2.5Gbe RJ45 ports (Intel® i226V)
4x 1Gbe SFP ports (Intel® i210IS)
2x 10Gbe SFP+ (Intel® X710)
Bypass 1x Segment (MCU control)
Expansion 1x PCI-E Gen5 x8 (for SSL card)
1x PCI-E Gen5 x8 (for IBN module)
IPMI N/A
Storage 1x 2.5” HDD/SSD
1x SATA DOM
1x 2280 M.2 slot
TPM TPM 2.0
I/O 1x LCM
3x LED (Status/HDD/Power)
1x RJ45 console
2x USB 3.0
1x Reset button
1x NMI button
Power Supply 600W 1+1 Redundant Power Supply
500W Single Power Supply
Dimensions 438(W) x 420(D) x 44(H) mm ± 0.3mm
Weight N/A
Operating Temperature 0°C~ 50°C
Storage Temperature -20° ~ 70°C
Operating Humidity 10% ~ 90%
Certification CE/FCC
INA3608 1U Rackmount Appliance, MBN3608, 13th Gen Intel® Alder Lake Core i, R680E PCH, 2x DDR5 UDIMM, 600W RPSU Barebone without CPU/RAM/HDD/IBN Card/SSL Card
DATASHEETS INA3608
CATALOGS Network Appliances (Vol.23.12)
USER'S MANUALS INA3608 V1.0
DRIVERS - SYSTEMS INA3608 Driver DVD
