Digital Signage Player

SI-654

11th Gen Intel® Core™ U-Series Processor Signage Player with Intel® SoC Integrated Graphics and Four HDMI 2.0

  • iSMART intelligent energy-saving & Observer remote monitoring technologies
  • 11th Gen Intel® Core™ U-Series Processors
  • 4x HDMI 2.0 with independent Audio output support
  • Built-in CEC and hardware EDID emulation functions with the software setting mode
  • 2x DDR4-3200 SO-DIMM, Dual channel, Max. 64GB
  • 1x M.2 B-Key (3042) for 4G LTE options
  • 1x M.2 E-Key (2230) for Wi-Fi, Bluetooth or capture card options
  • 1x M.2 M-Key (2280) for storage
  • Supports Intel® iAMT(11.0), TPM 2.0 and watchdog timer
  • Slim and segregated ventilation design
  • iSMART
  • Observer
  • Segregated Airflow Design

The SI-654 is an 8K digital signage player with a cooling fan powered by 11th Gen Intel® Core™ U-Series processors (formerly Tiger Lake). It is currently offered with an Intel® Core™ i7-1185G7E processor (12M Cache, up to 4.40GHz) integrating the high-performance Iris Xe GPU, Intel's 12-Gen graphics with 96EUs. Measuring 200 x 139 x 41 mm, the compact SI-654 can be easily installed in space-constraint environments. It houses four HDMI 2.0 connections to deliver up to 1x 8K display or 4x 4K displays, performing a vivid 8K resolution and ensuring a truly immersive audience's viewing experience.

Mainly designed for digital signage in busy places where there is a constant demand for practical information, the SI-654 features HDMI-CEC control, display status monitoring, flexible video wall configurations and hardware EDID emulation that prevents distorted or black screen due to display and cable connection issues. The industrial-grade SI-654 is perfectly suited for video wall solutions in airports, shopping malls and other commercial premises that require reliable 24/7 operation.

With IBASE advanced iSMART and Observer technologies, the player is equipped with low temperature boot protection, power resume control, power on/off scheduling, and hardware monitoring to enable continuous and stable operation of the system. The player supports TPM 2.0 for optimal cyber security and vPro for easy remote monitoring and management.

System Mainboard MBD654
CPU 11th Gen Intel® Core™ / Celeron® U-Series (TGL-U Platform) Processors
CPU Socket BGA-1449
Chipset SoC Integrated
Memory 2x DDR4-3200 SO-DIMM, Dual channel, Max. 64GB
Graphics Gen12 integrated Graphics, Up to 96EU
LAN 1st: 1x Intel® I211AT/ 1210AT
2nd: 1x Intel® I219LM (I7/I5)
1x Intel® I219V (I3)
Expansion Slots 1x M.2 E-Key (2230)
1x M.2 B-Key (3042)
1x UIM/SIM card slot
I/O Interface 4x HDMI 2.0
1x USB 2.0 (USB A-Type)
3x USB 3.1 @gen 2 (USB A-Type)
2x RJ45 for Gigabit LAN
1x RJ45 for RS232 serial port
1x Audio connector for Line-out
1x Power button
1x Power jack (+12V DC)
2x Power/HDD LED
Auto Control and Monitoring Watchdog Timer: 256 segments, 0, 1, 2…255 (sec/ min)
Power Requirement +12V DC
Construction Aluminum + SGCC
Weight 1.8 kgs (3.7 lbs)
Chassis Color Black & White
Storage 1x M.2 M-Key (2280) supports NVMe (PCI-E x4 / SATA)
Power Supply 84W power adaptor
Mounting Standard system bracket
Dimensions 200.8mm(W) x 139.3mm(D) x 41.2mm(H)
7.90" (W) x 5.48" (D) x 1.62" (H)
Operating Temperature 0°C~ 45°C (32°F~113°F)
Storage Temperature -20° ~ 80°C (-4°F~176°F)
Relative Humidity 10%~90% (non-condensing)
Vibration M.2: 5 grms / 5~500Hz / random operation
Certification CE, FCC Class-B, UKCA, cULus, LVD
Operating System Windows 10 IoT Enterprise RS5(64-bit)
Linux Ubuntu(64-bit)
SI-654-I7 Intel® Core™ I7-1185G7E processor (12M Cache, up to 4.40 GHz), 2x 4GB DDR4 3200 SO-DIMM, M.2 128GB and 84W power adaptor
SI-654-I5 Intel® Core™ I5-1145G7E processor (8M Cache, up to 4.1 GHz), 2x 4GB DDR4 3200 SO-DIMM, M.2 128GB and 84W power adaptor
SI-654-I3 Intel® Core™ I3-1115G4E processor (6M Cache, up to 3.9 GHz), 2x 4GB DDR4 3200 SO-DIMM, M.2 128GB and 84W power adaptor
SI-MK3B TV Mount

Drivers

Model Chipset Video Audio Network Others
SI-654

Intel(R) Chipset Software Installation Utility

Windows10

Intel(R) HD Graphics

Windows10

Realtek High Definition Audio

Windows10

Intel(R) Network

Windows10

Intel(R) ME 15.X

Windows10

Intel(R) Thunderbolt

Windows10
