Digital Signage Player
SI-606
4th Gen Intel® Core™ Desktop Processor-based Video Wall Signage Player with Six DP
- iSMART - for EuP/ErP power saving, auto-scheduling and power resume
- 6x DP 1.2 with independent audio output support
- Supports 4th Gen Intel® Core™ desktop processor
- 4x DDR3-1600 DIMM, Dual channel, Max. 32GB
- Flexible VW display configuration setting, Max. resolution: 11520 x 4320
- 2x RS232 serial ports
- 1x Mini PCI-E(full-size) for mSATA, Wi-Fi, Bluetooth or 4G LTE options
- 1x Mini PCI-E(full-size) for Wi-Fi, Bluetooth or 4G LTE
- 2x SATA III 2.5" HDD with RAID 1 support
- Compact and rugged design
The SI-606 six (6) DP1.2 digital signage player is based on AMD Radeon™ E8860 GPU that integrates 2GB of high speed GDDR5 frame buffer that features more than 2x the 3D performance of Radeon E6760 GPU. Driving six multiple independent displays with support for AMD Eyefinity Technology, SI-606 utilizes a 4th Generation Intel® Core™ i7-4770S Quad-Core 3.1 GHz with 8MB cache LGA1150 processor.
Supporting 5.4 Gbps DP 1.2 (4K resolution at 60Hz) with Multistreaming (MST), SI-606 is a powerful digital signage player that is perfect for the transportation, hospitality and corporate environments to provide specific and dynamic messaging that convey brand information as well as delivery highly target promotions. Supporting flexible video-wall display settings and resolutions of up to 11520 by 4320, it can drive signage in airports, restaurants, banks and shopping malls to reach a large audience.
SI-606 comes with IBASE's iSMART Sole Technology for Power on/off scheduling, power resume functions, low temperature guardian and intelligent OS recovery. Measuring 4129mm by 310mm by 47mm, SI-606 is available with an Intel® Core™ i7-4770S CPU, 32GB DDR3 memory, 128GB SSD storage and a 250W power supply. Onboard I/O connectivity includes 4x USB 3.0, 2x USB 2.0, 2x DSUB 9pin for 2x Gigabit LAN, 1x RS232 and 2x mPCIe expansion slots.
| System Mainboard | MBD60E |
| CPU | 4th Generation Intel® Core™ i7/i5/i3 and Pentium® QC/ DC processors |
| CPU Socket | LGA1150 |
| Chipset | Intel® Q87 PCH |
| Memory | 4x 8G DDR3-1600 DIMM, Max. 32GB |
| Graphics | AMD E8860 GPU with 128-bit wide, 2GB GDDR5, 72Gbps 640 Shader processors • AMD APP technology, OpenCL™ 1.24, DirectCom pute 11.1 • 768 / 48 GFLOPS single- / double-precision peak (600e/4.5Gbps) • Supports AMD Eyefinity technology |
| LAN | 1x Intel® Clarkville I218LM 1x Realtek RTL8111G-CG |
| Expansion Slots | 1x Mini PCI-E (full-size) for mSATA, Wi-Fi, Bluetooth or 4G LTE options 1x Mini PCI-E (full-size) for Wi-Fi, Bluetooth or 4G LTE |
| I/O Interface | 6x DP 1.2 with independent audio output 1x DVI-I for console 4x USB 3.0 ports 2x RJ45 for Gigabit LAN 1x DSUB 9pin for RS232 3x Microjack audio connectors for Line-in/Line-out/Mic Power LED for power on/off & HDD 1x power button 1x AC power inlet |
| Auto Control and Monitoring | 256 segments, 0, 1, 2...255 (sec/min) |
| Power Requirement | N/A |
| Construction | SGCC |
| Weight | 5.4Kg (11.9lbs) |
| Chassis Color | Black and white |
| Storage | 2x SATA III 2.5” HDD dock (supports RAID 1) |
| Power Supply | N/A |
| Mounting | Standard system bracket |
| Dimensions | 412mm(W) x 310mm(D) x 47mm(H) 16.22" (W) x 12.2" (D) x 1.85" (H) |
| Operating Temperature | 0°C~ 45°C (32°F~113°F) |
| Storage Temperature | -20°C ~ 80°C (-4°F~176°F) |
| Relative Humidity | 5~90% @ 45°C, (non-condensing) |
| Vibration | mSATA: 5 grms / 5~500Hz / random operation |
| Certification | CE, FCC Class B, cULus & CCC |
| Operating System | Windows XP, Win7 32/64-bit, Win8 64-bit, Win8.1 64-bit Win10 64-bit Enterprise, WEC 2013 |
| SI-606 | Signage Player with MBD60E (w/ AMD E8860 for 6x DisplayPort), with 4th Gen Intel® Core™ (DT) i7-4770S processor, 4x 8GB DDR3 DIMM, 2.5" 128GB SSD and 250W PSU. |
| SI-60X | Rack mounting bracket |
Drivers
| Model | Chipset | Video | Audio | Network | Others |
| SI-606 |
Intel Chipset Driver Windows 7 & 8 |
AMD Graphics Driver Windows 7 & 8 |
Realtek High Definition Audio Driver Windows 7 & 8 |
Intel LAN Driver Windows 7 & 8 (32bit)Realtek LAN Driver Windows 7&10 (64bit) |
Intel iAMT Driver Windows 7 & 8Intel USB 3.0 Driver Windows 7 |
